Model G0623X/G0623X3 (Mfg. Since 5/12)

-19-

inventory item: (figure 11)

Qty

ag. sliding table ............................................... 1

ah. sliding table support legs ........................ 2

ai. feet m12-1.75 x 75 w/Nuts ......................... 2

inventory item: (figure 10)

Qty

aa. miter Clamp ................................................ 1

ab. miter flip stop ............................................ 1

ac. miter handle w/flat Washer 8mm .............. 1

ad. miter gauge fence ..................................... 1

ae. miter gauge body ...................................... 1

af. miter guide bar .......................................... 1

figure 10. miter gauge items.

inventory item: (figure 12)

Qty

aJ. Crosscut brace Knobs m8-1.25 x 50 ......... 2

—flat Washers 8mm ................................. 2

—square Nuts m8-1.25 .............................. 2

aK. Crosscut fence Knob m8-1.25 ................... 1

—flat Washer 8mm ................................... 1

—Crosscut fence t-stud m8-1.25 x 60 ..... 1

al. Crosscut fence lock Knob m8-1.25 x 25 .. 1

am. pivot stud ................................................... 1

—special Washer 8 x 20mm ..................... 1

—square Nut m8-1.25 ................................ 1

an. push handle m12-1.75 x 14 ........................ 1

—flat Washer 12mm .................................. 1

—plastic Washer 12mm ............................. 1

—push handle t-Nut m12-1.75 .................. 1

other hardware (not shown)

Qty

Cap screws m10-1.5 x 25 (extension tables) .. 5
flat Washers 10mm (extension tables) ........... 5
lock Washers 10mm (extension tables) ......... 6
set screws m8-1.25 x 25 (extension tables) ... 6
hex Nuts m8-1.25 (extension tables) .............. 6
hex bolts m6-1 x 16 (fence scale) .................. 2
hex bolt m6-1 x 25 (fence scale) .................... 1
flat Washers 6mm (fence scale) ..................... 3
lock Washers 6mm (fence scale) ................... 3
hex Nuts m6-1 (fence scale) ........................... 3
Cap screws m6-1 x 16 (Ct support leg) ......... 4
lock Washers 6mm (Ct support leg) ............. 4
flat Washers 6mm (Ct support leg) ............... 4
Cap screws m5-.8 x 12 (switch) ....................... 2
lock Washers 5mm (switch) ............................ 2
Cap screws m10-1.5 x 30 (st leg plates) ...... 4
lock Washers 10mm (st leg plates) .............. 4
Cap screw m10-1.5 x 25 (hose support) ......... 1
flat Washers 10mm (hose support) ................. 2
hex Nut m10-1.5 (hose support) ...................... 1

figure 11. sliding table items.

figure 12. miscellaneous knobs and hardware.

ao. support leg t-slot plates .......................... 2

ap. sliding table t-studs m12-1.75 x 35 .......... 2

—flat Washers 12mm ............................... 2

—lock Washers 12mm .............................. 2

—hex Nuts m12-1.75 ................................. 2
