Model G0623X/G0623X3 (Mfg. Since 5/12)

-3-

figure 1. main view of machine features and controls.

identification

a. crosscut table—provides a wide, stable

platform for supporting full-size panels during
crosscutting operations.

b. flip stops—used for quick measurements

for crosscutting.

c. crosscut fence—used during crosscutting

operations. features a scale and multiple
flip-style stop blocks for precise, repeatable
crosscutting operations.

d. sliding table—Conveniently glides the

workpiece through the blade with effortless
precision and ease.

e. blade guard—fully-adjustable blade guard

maintains maximum protection around the
saw blade and a 2½" dust port effectively
extracts dust from the cutting operation.

f. rip fence—fully adjustable with micro-

adjustment knob for precision adjustments.
fence face can be positioned for standard
cutting operations, or in the lower position for
blade guard clearance during narrow ripping
operations.

g. switch—features push-button controls start-

ing and stopping the table saw motor.

h. blade angle handwheel—adjusts the angle

of the saw blades.

i. blade elevation handwheel—located

on the right-hand side of the cabinet, this
handwheel adjusts the height of the main
saw blade.
