Model G0623X/G0623X3 (Mfg. Since 5/12)
-39-
the riving knife included with this machine is
0.090" (2.3mm) thick and is only designed for 10"
diameter blades.
When choosing a main blade, make sure the
blade size meets the requirements listed below.
the thickness of the blade body and teeth can be
measured with calipers or any precision measur-
ing device.
blade size requirements:
•
body thickness: 0.079"–0.090"
(2.0mm–2.3mm)
• Kerf (tooth) thickness: 0.122"–0.129"
(3.1mm–3.3mm)
blade requirements
figure 62. ripping blade.
blade selection
This section on blade selection is by no means
comprehensive. Always follow the saw blade
manufacturer's recommendations to ensure safe
and efficient operation of your table saw.
Ripping Blade Features:
•
Best for cutting with the grain
• 20-40 teeth
• Flat-top ground tooth profile
• Large gullets for large chip removal
Flat
Top
Blade
safety tips
your safety is important. the tips below are
intended to supplement
section 1: safety.
but remember, no safety list can cover every situ-
ation. the operator is ultimately responsible for
their own safety, as well as the safety of bystand-
ers. every cutting operation is uniquely different
and may require safety equipment or safety pro-
cedures not mentioned in this manual.
please follow these safety tips every time
you use your saw:
• stand to the left of the blade line-of-cut when
performing a cutting operation.
• turn OFF the saw and allow the blade to
come to a complete stop before removing
cut-off pieces.
• make sure that the riving knife is always
aligned with the main blade before cutting!
• always position the blade guard to the correct
height above the workpiece.
• Carefully plan each cutting operation to avoid
injuries.
• When you release the sliding table lock,
make sure that the knob is positioned so that
it will not lock the table during a cut.
• plan your cut to avoid putting your hands
near the blade or reaching across the blade.
