Model G0623X/G0623X3 (Mfg. Since 5/12)
-41-
6. use the arbor wrenches to remove the arbor
nut and arbor flange, as shown in figure
68, then pull the old blade off the arbor. The
arbor nut has left-hand threads and loosens
by turning clockwise.
— if you changed the diameter of the blade
during this procedure, adjust the riving knife
according to
riving Knife installation &
removal on page 38.
8. move the blade cover back into its original
position next to the blades, then center the
sliding table.
4. pull the blade cover away from the blades to
expose the mounting assembly. (the blade
cover is held closed with a magnet.)
5. insert the arbor lock tool into the hole shown
in figure 67, then rotate the blade by hand
until the arbor lock tool seats.
figure 68. replacing the main blade.
arbor
lock
tool
this saw performs best with high-quality sharp
blades. Whenever the blades become dull, replace
or have them sharpened.
to change the main blade:
1. disCoNNeCt saW from poWer!
2. move the blade tilt to 0° (blade 90° to table)
and raise the main blade as far as it will go.
3. move the sliding table out of the way to
expose the lower blade cover that covers the
blades and riving knife, as shown in
figure
67.
changing main
blade
figure 67. blade cover made accessible with
sliding table moved out of the way.
hole for arbor
lock tool
7. install the blade as shown in figure 69, mak-
ing sure the teeth face toward the scoring
blade. do Not overtighten the arbor nut.
figure 69. main blade installation and order of
assembly.
tighten
loosen
blade Cover
Before proceeding with the next step, wear
gloves to protect your hands while handling
and installing the blade.
