Model G0623X/G0623X3 (Mfg. Since 5/12)
-79-
main motor parts list
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
201V2 P0623X0201V2 BLADE GUARD COVER V2.05.12
235
PCAP77M
CAP SCREW M12-1.75 X 30
202V2 PLN05M
LOCK NUT M10-1.5
236
P0623X0236
SHAFT
203V2 PCAP64M
CAP SCREW M10-1.5 X 25
237
P0623X0237
BUSHING
204
P0623X0204
RIVING KNIFE MOUNTING BLOCK
238
PBHS22M
BUTTON HD CAP SCR M8-1.25 X 20
205
PK34M
KEY 5 X 5 X 20
239
P0623X0239
BUSHING
206
P0623X0206
LOCATING BLOCK
240
PWF08M
FENDER WASHER 8MM
207
PN09M
HEX NUT M12-1.75
241
PLW04M
LOCK WASHER 8MM
208
P0623X0208
LINK PLATE
242
PBHS03M
BUTTON HD CAP SCR M8-1.25 X 16
209
P6004-2RS
BALL BEARING 6004-2RS
243
P0623X0243
MAIN ARBOR CSA
210
P0623X0210
WAVE WASHER 26 X 34MM
244
P0623X0244
ARBOR FLANGE CSA
211
P0623X0211
COLLAR
245
P0623X0245
LOCATING PIN
212
P0623X0212
GIB PLATE
246
PB73M
HEX BOLT M10-1.5 X 50
213
PBHS08M
BUTTON HD CAP SCR M10-1.5 X 35
247
P0623X0247
RIVING KNIFE WASHER 10MM
214
PSS03M
SET SCREW M6-1 X 8
248V2 P0623X0248V2
RIVING KNIFE V2.05.12
215
P0623X0215
ARBOR PULLEY TYPE M
249
P0623X0249
ARBOR WASHER
216
PW06M
FLAT WASHER 12MM
250
P0623X0250
HOSE 3" X 60CM
217
PLW04M
LOCK WASHER 8MM
251
P0623X0251
HOSE CLAMP 3-1/4"
218
PVM20
V-BELT M-20 3L200
252
PCAP119M
CAP SCREW M12-1.75 X 55
219
PCAP14M
CAP SCREW M8-1.25 X 20
253
P0623X0253
IDLER
220
PSS02M
SET SCREW M6-1 X 6
255
PN09M
HEX NUT M12-1.75
221
P0623X0221
MOTOR PULLEY TYPE M
256
PN09M
HEX NUT M12-1.75
222
P0623X0222
SHAFT
257
P0623X0257
ROTATE PLATE
223
P0623X0223
MAIN MOTOR MOUNTING PLATE
258
PR20M
INT RETAINING RING 28MM
224
PW06M
FLAT WASHER 12MM
259
P0623X0259
BUSHING
225
PLW05M
LOCK WASHER 12MM
260
P0623X0260
BELT 15 X 1140
226
PB25M
HEX BOLT M12-1.75 X 25
261
P0623X0261
PLATE
227
PK28M
KEY 7 X 7 X 29
262
P0623X0262
BUSHING
229
PCAP14M
CAP SCREW M8-1.25 X 20
263
PLN07
LOCK NUT 5/8-11
230
PLW04M
LOCK WASHER 8MM
264
P0623X0264
BUSHING
231
PCAP14M
CAP SCREW M8-1.25 X 20
265
PLW05M
LOCK WASHER 12MM
232
PLW04M
LOCK WASHER 8MM
266
P6001ZZ
BALL BEARING 6001ZZ
233
PWF08M
FENDER WASHER 8MM
267
P0623X0267
EXTENSION SPRING
234
P0623X0234
ROTATE PLATE
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
228
P0623X0228
MOTOR 5HP 1-PH
228A
P0623X30228A
MOTOR 7.5HP 220V/440V 3-PH
228-1 P0623X0228-1
MOTOR FAN COVER
228-1A P0623X30228-1A MOTOR FAN COVER
228-2 P0623X0228-2
MOTOR FAN
228-2A P0623X30228-2A MOTOR FAN
228-3 P0623X0228-3
JUNCTION BOX
228-3A P0623X30228-3A JUNCTION BOX
228-4 P0623X0228-4
CAPACITOR COVER
228-5 P0623X0228-5
S CAPACITOR 400M 250V
228-6 P0623X0228-6
CAPACITOR COVER
228-7 P0623X0228-7
R CAPACITOR 30M 500V
G0623X3 7.5HP, 220V/440V, 3-PHASE MOTOR
G0623X 5HP, 230V, SINGLE-PHASE MOTOR
