Power connection box, Disconnect switch (as recommended), 440v wiring diagram – Grizzly G0623X3 User Manual
Page 77
Model G0623X/G0623X3 (Mfg. Since 5/12)
-75-
READ ELECTRICAL SAFETY
ON PAGE 72!
1
2
3
4
EMERGENCY
STOP SWITCH
MAGNETIC SWITCH
ASSEMBLY
MOTOR @ 440V
BLADE GUARD
LIMIT SWITCH
1
2
POWER
CONNECTION
BOX
Hot
Hot
440 VAC
3-Phase
Ground
DISCONNECT SWITCH
(AS RECOMMENDED)
1
2
3
1 12 2 10 3 11
4
5
6
7
8
9
A
AMP
RESET
96
98
T1/2
T3/6
NO14
T2/4
L1/1
L3/5
NO13
L2/3
95
8
12
SET @ 10
NC15
SDE
NC16
Ground
1/2
3/4
5/6
OL RELAY RA-20
SDE MA-18
440V
A2
g0623X3 7.5 hp 440v Wiring diagram
440v Wiring diagram
