DRIVE TRAIN
Front Axle Assembly
Starting Serial No. 0155299S
Original Issue 3-90
6-12
Item Part No. Qty. Description Of Part
9104-3291 1 FRONT AXLE ASSY (includes items 1
thru 4)
1 9104-4444 1 AXLE HOUSING ASSY (see page
6-13 for details)
2 9104-4448 1 DIFFERENTIAL CARRIER ASSY
(see page 6-14 for details)
3 1 AXLE SHAFT & PLANETARY
WHEEL END ASSY (see page 6-15
for details)
4 8319-3009 4 FITTING
5 9104-3146 24 LUG NUT (lubricate and torque to
350-400 ft. lbs.)
NOTE: ONLY ITEMS WITH PART
NUMBERS ARE AVAILABLE
FOR SERVICE.
