ENGINE & ATTACHING PARTS
Engine Right Side View
Starting Serial No. 0155299S
Original Issue 3-90
Revised 12-29-95
5-3
Item
Part No.
Qty.
Description Of Part-
1
9108-3155
1
SHUT-OFF VALVE
2
8871-1213
1
PIPE COUPLING, 1/2
3
8870-1070
1
PIPE NIPPLE, 1/2X1-1/2
4
7738-3540
1
COOLANT RESTRICTOR ORIFICE
5
9104-3253
1
FAN BLADE
6
9103-3246
1
OIL PRESSURE SENDER
7
9108-1388
1
TAPPED BAR
8
8820-1009
2
HEX HD CAPSCREW, 1/4-20X2, GR5
9
8855-1009
2
LOCKWASHER, 1/4
10
8850-1004
2
HEX NUT, 1/4-20
11
8688-3075
2
TUBE FITTING
12
1
NYLON TUBE, 3/8 O.D. 15" LONG
13
7738-3259
1
FAN SPACER
14
7738-3204
1
FAN BELT (v-ribbed)
15
9020-6124
1
WATER TEMPERATURE SENDER
16
8871-1384
1
REDUCING BUSHING, 1/2X1/4
17
9104-1558
1
JUMPER WIRE
18
8668-3480
1
CRIMP-ON CONNECTOR
19
2474-1047
1
PRESSURE SWITCH
20
7738-3202
1
FUEL FILTER (spin on, primary)
21
7738-3203
1
FUEL FILTER (spin on, secondary)
22
8209-2118
1
FUEL LINE HOSE, 36" LONG
23
8874-1800
1
HOSE NIPPLE
24
8348-3497
1
HOSE CLAMP
25
8319-1006
11
HEX HD CPASCREW, M10X1.5X40
26
8319-1013
11
LOCKWASHER
27
9103-3319
1
TRANSMISSION ASSY (see page 6-1
thru 6-10 for details)
28
9103-3283
1
OIL TEMPERATURE SENDER
29
8820-1067
4
HEX HD CAPSCREW, 1/2-13X1-1/2,
GR5
30
8855-1013
4
LOCKWAHSER, 1/2
Item
Part No.
Qty.
Description Of Part-
31
8471-1427
2
FLANGE HALF
32
9104-3176
1
SUCTION TUBE
33
8859-1106
1
O-RING
34
8866-2067
2
ELBOW, 90 DEGREES (includes item
35)
35
8859-1207
2
O-RING
36
9020-0811
1
GROUND CABLE (see page 11-2 for
details)
37
8319-1004
1
HEX HD CAPSCREW, .30M12X1.75
38
8856-1111
1
FLAT WASHER, 1/2
39
9104-3324
1
FUEL LINE HOSE
40
8668-3106
1
HOSE CLAMP
41
9104-4351
1
FUEL LINE HOSE
42
9104-4352
1
PUMP GASKET
43
9104-3259
1
PILOT PUMP ASSY (see page 10-23
for details)
44
8667-1112
1
PUMP GASKET
45
9104-3252
1
CUMMINS DIESEL ENGINE (for parts
information see separate engine
manual)
46
8319-1021
2
HEX HD CAPSCREW, M10X1.5X30
47
8319-1013
2
LOCKWASHER, M10
48
8820-1536
8
HEX HD CAPSCREW, 3/8-24X1-1/2,
GR5 (lubricate and torque to 25-30 ft.
lbs.)
49
8856-1109
8
FLAT WASHER, 3/8
50
9108-3338
1
HEX HD CPASCREW, M16X2X120
51
9108-1158
2
REBOUND WASHER
52
8668-1227
1
SHOCK MOUNT
53
8319-1039
4
HEX HD CAPSCREW
54
8856-1108
4
FLAT WASHER, 5/16
MPC-414
