Page 44
DRIVE TRAIN
Transmission Case & Converter Housing
Starting Serial No. 0155299S
Original Issue 3-90
6-4
Item
Part No.
Qty.
Description Of Part
1
8820-1046
9
HEX HD CAPSCREW, 3/8-16X3-3/4,
GR5
2
8855-1011
9
LOCK WASHER, 3/8
3
Ref
MODULATOR VALVE ASSY (see
page 6-10 for details)
4
9103-4245
1
GASKET
5
7710-4284
2
DETENT BALL
6
7710-4285
2
DETENT SPRING
7
7710-4112
1
PIPE PLUG
8
7710-4096
1
AIR BREATHER
9
9103-4246
1
CONVERTER HOUSING ASSY
(includes items 10 thru 13)
10
9104-4050
1
LUBE BYPASS TUBE
11
9104-4051
1
O-RING
12
9104-4052
1
TUBE CLIP
13
7710-4102
1
HEX HD CAPSCREW
14
7710-4103
1
LOCK WASHER
15
9020-4800
1
SCREEN ASSY
16
9020-4799
1
SCREEN GASKET
17
9002-7267
2
PIPE PLUG
18
7710-4116
1
PIPE PLUG
19
7710-4086
16
HEX HD CAPSCREW
20
7710-4085
16
LOCK WASHER
21
7710-4116
1
PIPE PLUG
22
7710-4097
1
CONVERTER HOUSING SLEEVE
23
9020-4823
1
DIPSTICK TUBE
24
9020-4824
1
DIPSTICK
25
7710-4109
1
TUBE SLEEVE
26
7710-4111
1
O-RING
27
7710-4116
1
COVER PIPE PLUG
28
9020-4798
1
COVER & PLUG ASSY (includes
item 27)
Item
Part No.
Qty.
Description Of Part
29
7710-4085
15
LOCKWASHER
30
8820-1053
9
HEX HD CAPSCREW, 7/16-1-3/4,
GR5
31
7710-4086
6
HEX HD CAPSCREW
32
9020-4806
6
OIL BAFFLE SEAL
33
9020-4807
1
OIL BAFFLE
34
9020-4802
1
GASKET
35
7710-4112
2
PIPE PLUG
36
9020-4804
1
CLUTCH LUBE TUBE
37
7710-4119
1
MAGNETIC DRAIN PLUG
38
7710-4057
1
O-RING
39
9020-4809
1
SUCTION TUBE ASSY
40
7710-4107
1
TUBE SLEEVE
41
7710-4111
1
O-RING
42
8855-1010
2
LOCK WASHER, 5/16
43
8820-1017
2
HEX HD CAPSCREW, 5/16-18X5/8,
GR5
44
7710-4098
1
GASKET
45
7710-4113
1
DOWEL PIN
46
7710-4116
1
O-RING
47
7710-4109
1
TUBE SLEEVE
48
7710-4048
2
O-RING
49
7710-4110
1
LOW SPEED CLUTCH PRESSURE
TUBE
50
7710-4112
1
PIPE PLUG
51
7710-4118
1
PIPE PLUG
52
9020-4817
1
TRANSMISSION CASE ASSY
(includes items 25, 32, 33, 36, 38,
39, 40, 42, 43, 47, 49)
53
7710-4113
2
DOWEL PIN
