2.

Remove the server from the rack (on page 13).

3.

Remove the access panel (on page 14).

4.

Disconnect all internal cables connected to existing expansion boards.

5.

Remove the PCI riser board assembly (on page 14).

6.

Remove all installed expansion boards.

7.

Remove the PCIe riser board from the assembly.

8.

Install the optional PCI-X riser board.

9.

Install a PCI-X expansion board ("Expansion board option" on page 32).

IMPORTANT:

The server does not power up if the PCI riser board assembly is not seated

properly.

10.

Install the PCI riser board assembly (on page 15).

11.

Connect all internal cables for expansion boards.

12.

Install the access panel.

13.

Install the server into the rack.

Hardware options installation 34
