HP TC2120 - Manual (Page 33)

27
Chapter 3 Installing and Configuring
Memory Modules
The main memory for the hp server tc2120 is implemented using four memory slots on the system board and it
supports up to 4 GB (1 GB x 4) of memory. The server only supports HP 184-pin, PC2100 (266 MHz), 3.3V,
buffered, ECC DDR DIMMs and ships with at least one 128 MB DIMM installed.
To ensure you have the correct DIMMs before installation, refer to one of the following for a list of qualified
DIMMs:
• HP web site at: http://www.hp.com/
• HP Customer Service
Tools Required
Use an anti-static service kit (3M 8501/8502/8503 or equivalent). This kit includes a static-dissipating work
surface, a chassis clip lead, and a wrist strap.
Figure 3-11. Installing the Optional Backup Tape Drive
NOTE Use only memory modules provided for your hp server model.
The use of other memory modules is not supported. Install
only 128 MB, 256 MB, 512 MB, or 1 GB buffered ECC DDR
DIMM modules.
