110
Chapter 8 Parts Identification
Replaceable Parts List
The items in this list and the corresponding item numbers in the respective Exploded Views apply to both
models of the hp server, except where noted.
NOTE The part numbers listed below were available at the time of
publication. Part numbers may change after
publication. Order
parts by the number listed below; HP's parts price list database
will generally contain a reference to the revised part number.
If a system board needs to be replaced, remove processor
modules, DIMMs, or adapter boards and transfer these to the
new board. Ensure all jumper and switch settings on the old
board are transferred to the new board.
Item No. Description Spare Part Number
1 Top Cover 311181-001
2 Right Side Cover (not removable) 311181-001
3 Upper Front Bezel 311172-001
4 Filler Panel (5¼”) with vents 311172-001
5 Lower Front Bezel with Power Button 311186-001
6 Control Cable Kit (with Power Switch) 311177-001
7 Left Side Cover 311171-001
8 Chassis Not available
9 FDD (Flexible disk drive) tray 311173-001
10 Flexible disk drive 3 1/2 inch 233409-001
11a CD-ROM Drive 48x IDE 288894-001
11b DVD Drive 16x/40x
12/14 CD-ROM Tray 311173-001
13 Tape Drive, SureStore, DAT24I (Optional)
14/12 Backup Tape Drive Tray 311173-001
15a Hard Disk Drive 40 GB, 7200 RPM (IDE model) 232008-001
15b Hard Disk Drive 80 GB, 7200 RPM (IDE model) 287685-001
15c Hard Disk Drive 36 GB, 10K RPM (SCSI model) 177987-001
16 5 1/4 inch Tray for 3rd HDD 311173-001
17 Spacer/shield (RFI) Not available
18 Drive Rails
19a Hard Disk Drive 40 GB, 7200 RPM (IDE model) 232008-001
19b Hard Disk Drive 80 GB, 7200 RPM (IDE model) 287685-001
