HP TC2120 - Manual (Page 120)

114
Chapter 9 Specifications
Power Supply Specifications
Hardware Specifications
Parameter Characteristics
Input Type Manual voltage selection
Input - Maximum
Range 100 to 127 VAC @ 50/60 Hz
200 to 240 VAC @ 50/60 Hz
Operating Current 100 to 127 VAC @ 7.0 A
200 to 240 VAC @ 3.5 A
Inrush Current 90 A (cold) 120 A (warm)
Operating Power 250 W Continuous
Specification Characteristics
Processors The hp server tc2120 supports the following
processors:
• Northwood Pentium 4 processors 2.4 GHz and above
with 533 MHz FSB and 512KB L2 cache memory
• Celeron processors 1.8GHz and above with 400MHz
FSB and 128KB L2 cache memory
Chipset ServerWorks Grand Champion SL chip set with 33
MHz PCI and 133 MHz FSB speed support
Memory Supports up to four ECC DDR DIMMS for a maximum
total of 4.0 GB. Supported DIMM type and sizes:
128MB, 256MB, 512MB, or 1GB buffered, 184-pin,
3.3 volts, 72 bits wide, ECC single-bit correcting,
multi-bit detecting.
Video Embedded ATI Rage XL (8MB SDRAM)
SCSI SCSI model only; single channel Ultra-160 SCSI cable
(3 internal connectors), Ultra 160 SCSI LED cable
IDE Embedded Enhanced-IDE 33/66/100 dual-channel con-
troller
PCI Bus Five full-length 64-bit PCI slots at 33MHz. Four slots
support 3.3 volt cards and 1 slot (blue connector)
supports a +5 volt card.
LAN Embedded 10/100/1000 Broadcom 5702 LOM
connection
