Figure 1-4, Belo – HP TC4100 User Manual
Page 9
7
Chapter 1
Control and Indicators
Figure 1-4. HP Server tc4100 Rack Bezel
NOTE
If the HP Server Remote Management Card accessory is installed, certain LEDs will
function differently. The table below describes the LED functionality with and without
the HP Server Remote Management Card accessory.
i
Hot Swap
Hard Drives
(8 bays)
CD-ROM
Drive
Information
Pullout Tab
Control
Panel
Indicators
Flexible Disk
Drive (Floppy)
Hard Drive
Lock
Non-hot-swap
Drives (optional)
Rack Tie
Down Screw
(2 places)
