Sizing and
Application
Articulated Type
Steering
Forward
E1
E2
B1
B2
C2
C1
S1
OS1
OS2
CG1
CG2
Twin Cylinders with a Dual Wheel Set
Forward
E1
E2
B1
B2
C2
C1
S1
OS1
OS2
CG1
CG2
Twin Cylinders with a Single Wheel Set
Eaton’s Hydraulic Division
has developed a computer
program to assist articulated
vehicle designers with
a steering system analysis.
This analysis can provide
basic system sizing,
pressure requirements or a
complete system analysis
including dynamic
characteristics.
This analysis is intended to
be used as a guide only and
is not to be used solely as
the final determination of
system design. Other
factors and variables will
have to be considered.
To receive output from this
program, provide
the required information by
using the form on
the following page.
Contact an Eaton Hydraulics
Division Sales Representative
or send it to:
Marketing Product
Manager—Steering
Eaton Hydraulics
14615 Lone Oak Rd.
Eden Prairie, MN 55344
