30 EATON Char-Lynn Steering Catalog C-STOV-MC001-E1 July 2006
Steering Control
Units—Series 10
Model Code—
Ordering
Information
The following 32-digit coding system has been developed to
identify all of the configuration options for the Series 10
steering control units. Use this model code to specify a unit
with the desired features. All 32-digits of the code must be
present when ordering. You may want to photocopy the
matrix below to ensure that each number is entered in the
correct box.
1,2,3 Product Series ADR Series 10 Steering Control
Unit
4 Unit Type A Standard
B Dual Displacement
C Wide Angle
D 2-Speed
E 2-Speed with Wide Angle
G Dual Displacement with Wide
Angle
V Versa Steer, Wide Angle
5 Nominal Flow Rating 1 11 l/min [3 GPM]
(Open Center)
2 23 l/min [6 GPM]
(Closed Center and LS)
3 45 l/min [12 GPM]
(OC, CC, and LS)
4 19 l/min [5 GPM]
(Q-Amp)
5 38 l/min [10 GPM]
(Q-Amp)
6 76 l/min [20 GPM]
(Q-Amp)
7 23 l/min [6 GPM]
(Open Center)
6 Inlet Pressure Rating 1 276 bar [4000 PSI]—(Load
sensing and closed center)
2 207 bar [3000 PSI]—
(Open center)
7 Return Pressure A 21 bar [305 PSI] Max.—
Rating (standard rating*)
B 10 bar [145 PSI] Max.
8-9 Displacement 01 352 [21.5] / 60 [3.6]
cm3/r [in3/r] — 02 218 [13.3] / 60 [3.6]
Dual Displacement 03 290 [17.7] / 60 [ 3.6]
Combined/Manual 04 440 [26.8] / 146 [8.9]
05 231 [14.1] / 85 [5.2]
8-9 Displacement 40 60 [3.6]
cm3/r [in3/r] 43 75 [4.5]
45 95 [5.9]
48 120 [7.3]
50 145 [8.9]
51 160 [9.7]
52 185 [11.3]
54 230 [14.1]
57 295 [17.9]
59 370 [22.6]
61 460 [28.2]
64 590 [35.9]
66 740 [45.1]
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
A D R A A A A A 0 1 A A
Model Code — Series 10 Steering Control Units
1-8 GPM
8-16 GPM
* 12 GPM open center requires 145psi back pressure
** All Q-amp applications need approval from an Eaton Applications Engineer
10 Flow Amplification** A None (No Q-Amp)
B 1.6 : 1.0 Ratio†
C 1.6 : 1.0 Ratio
(with Manual Steering)†
E 2.0 : 1.0 Ratio
(with Manual Steering)†
G 1.3 : 1.0 Ratio
(with Manual Steering)†
†Use with closed center or
load sensing only.
11 Neutral Circuit A Open Center
C Closed Center
D Load Sensing, Static Signal
E Load Sensing, Dynamic Signal
F Open center with
Power Beyond
12 Load Circuit A Non-Load Reaction
B Load Reaction (Open Center
3,8 - 30 l/min [1 - 8 GPM] Only
D Non-Load Reaction,
Cylinder Damped
13,14 Special Spool/Sleeve 00 None
Modification
15,16 Valve Options
Manual Load Inlet Cylinder Anti- Inlet
Steering Sensing Check Relief Cavitation Relief
Check Relief Valve Valve Valve Valve
01 •
02 • •
03 • •
04 • • •
05 • •
06 • • •
07 • • •
08 • • • •
09 • • • • •
10 • • • • •
11 • • •
Continued on next page
