EATON Char-Lynn Steering Catalog C-STOV-MC001-E1 July 2006 81
Steering System
Components
Columns
Product
Information
Three Bolts 1/2-13 UNC x ( Z + 13,4 [.53])
Mounting
Bracket Z Dim.
13,4 [.53] Max.
Note: Series 40 is too heavy
for column mounting —
use column with or
without mounting tabs
LS
PP
12,9
[.51]
67,5
[2.66]
40,7
[1.60]
81,3
[3.20]
Series 40
Must use three bolts Into
steering control unit
mounting bosses opposite
port face.
Mounting Bracket or Bulkhead
T
L R
P
15,0 [.59]
41,5 [1.635] Pilot Dia.
M6 x 1,0-6H
18,5 [.73] Min.
Deep (4)
59,00
[2.323]
Dia.
5,8 [.23]
W Dim.
Cap Screw (3 or 4)
M6 x (W + 12,2 [.48])
Cap Screw (1)
M6 x 1,0
12,2 [.48] Max.
7,5 [.30] Min.
Round Series 5
Must use three
bolts minimum.
