56 EATON Char-Lynn Steering Catalog C-STOV-MC001-E1 July 2006
Torque Generator
Model Code
Ordering
Information
The following 20-digit coding system has been developed to
identify all of the configuration options for the torque
generator. Use this model code to specify a torque
generator with the desired features. All 20 digits of the code
must be present when ordering. You may want to
photocopy the matrix below to ensure that each number is
entered in the correct box.
1,2,3 Product Series ABP Torque Generator
4,5,6 Circuit Type .
and Ratings
A4A 15,1 l/min [4 GPM] Open Center
—Max Inlet 69 bar [1000 PSI]
Out 3 bar [ 50 PSI]
D4C 15,1 l/min [4 GPM] Open Center
Power Beyond
Inlet
138 bar [2000 PSI]
Out 3 bar [50 PSI]
Aux. (PB) 138 bar [2000 PSI] Dp
(Inlet – out) <69 bar
[1000 PSI]
(Limited to 76 [4.7], 80 [4.9],
96 [5.9] cm3/r [in3/r])
E4B 15,1 l/min [4 GPM] Open Center
with High Back Pressure
(Case Drain)
Inlet
172 bar [2500 PSI]
Out 103 bar [1500 PSI]
Aux. (CD) 3 bar [50 PSI] Dp (Inlet –
out) <69 bar [1000 PSI]
C4D 15,1 l/min [4 GPM] Load Sensing
Dynamic Signal
Inlet
69 bar [1000 PSI]
Out 3 bar [50 PSI]
Aux. (LS) 69 bar [1000 PSI]
7,8 Displacement 08 76 [4.7] Gerotor
cm3/r [in3/r] 10 96 [5.9] Gerotor
17 160 [9.7] Gerotor
58 80 [4.9] Geroler
60 102 [6.2] Geroler
66 160 [9.6] Geroler
9 Ports A 2 x .625 inch Dia. Manifold Ports
with 2 x 5/16-18 UNC Mounting
Holes (use with port block) -
open center only
B 3 x .625 inch Dia. Manifold Ports
with 3 x 5/16 - 18 UNC Mounting
Holes (use with port block)
C 2 x 9/16 SAE Ports—
open center only
D 3 x 9/16 SAE Ports
E 2 x G3/8 (BSP) Ports—
open center only
F 3 x G3/8 (BSP) Ports
10 Shaft Bearings 0 None
1 Output Shaft Needle Bearings
11 Integral Valves 0 None
12 Input Torque 1 Standard
13 Shaft Ends A 22,17 [.874] Dia. with Keyway and
Cross Hole
14 Shaft Seals 1 Quad Rings
15 Mounting A 5/16-18 UNC
Threads
16,17 Special Feature 00 None
01 Port Block Installed
18 Paint and A Black Primer
Packaging
19 Identification 1 Eaton Product Number on
Nameplate
20 Eaton Assigned B Assigned Design Code
Design Code
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
A B P 1 0 A 1 1 A A B
Nos Feature Code Description Nos Feature Code Description
