EATON Char-Lynn
Steering Catalog C-STOV-MC001-E1 July 2006
21,22,23,24
Ports and CAFA
4 x G 1/2 (BSP) Straight Thread
Mounting
Ports
Threads
G 1/4 (BSP) LS Straight Thread Port
(continued)
on Side
2 x M12 Mounting Threads Port
Face
4 x M10 Mounting Threads
Mounting Face
CAGA
4 x G 1/2 (BSP) Straight Thread
Ports
G 1/4 (BSP) LS Straight Thread Port
on Port Face
2 x M12 Mounting Threads Port
Face
4 x M10 Mounting Threads
Mounting Face
DAAA
Dash 08 STC® Ports ***
None (No Additional Port)
2 x M10 Mounting Threads Port
Face
4 x M10 Mounting Threads
Mounting Face
DAHA
Dash 08 STC® Ports ***
Dash 06 STC® Port on Side
2 x M10 Mounting Threads Port
Face
4 x M10 Mounting Threads
Mounting Face
DAJA
Dash 08 STC® Ports ***
Dash 06 STC® Port Face
2 x M10 Mounting Threads Port
Face
4 x M10 Mounting Threads
Mounting Face
25
Mechanical
A
Internal Involute Spline,
Interface
12 Tooth 16/32 DP 30° PA
26
Input Torque
3
Standard
27
Fluid Type
A
See Eaton Technical
Bulletin 3-401
28,29
Special Features
AA
None
30
Paints and Packaging 1
Black Primer
31
Identification
0
Eaton Product Number on
Nameplate
32
Eaton Assigned
B
Assigned Design Code
Design Code
Housing
Release Sleeve
STC Hose/Connector
Retaining Ring
Backup Washer
O-ring
STC Port
Dash 08 Port Face (4)
Dash 06 LS Port Side (1)
STC
®
—Aeroquip
Patent numbers: 5,553,895
5,226,682
5,570,910
Steering Control
Units—Series 10
Model Code—
Ordering
Information—
Continued
*** STC with inlet check requires threaded adapter. Contact your Eaton Account Representative for assistance.
Nos
Feature
Code Description
