EATON Char-Lynn Steering Catalog C-STOV-MC001-E1 July 2006 5
Description and
Advantages
Torque Generator
Char-Lynn torque generators have been completely
redesigned to meet the needs of the changing
marketplace. These torque generators have served
the industry well, providing:
• Power assist for vehicle steering
• Power assist on gates and valves, eliminating the
large hand wheels
• Powerful rotary motion with effortless manual rotary
input on numerous other applications
Today’s market includes power steering on electric lift
trucks. These new torque generators have been designed
with features that greatly improve the operator’s comfort as
well as the vehicle’s performance.
Use the Torque Generator as rotary power assist for:
• Large indexing tables
• Manually operated gates and valves
• Manual positioning devices
• Mechanical steering systems
• Turntables
SERIES 217, 227
Displacement 76 - 160 cm 3 /r 4.7 - 9.6 in 3 /r
Flow 15 l/min 4 GPM
Pressure 69 and 172 bar 1000 and 2500 PSI
STEERING COLUMNS (204-XXXX-XXX)
Jacket Length 56 - 836 mm 2.2 - 33 inch
Horn Wire with and without with and without
Upper Ends 10 Upper End Types 10 Upper End Types
Customized Steering Columns
Char-Lynn columns can be custom built to your
exact specifications. The column and mounting
flange is of a sturdy single weldment design. These
columns have high thrust and side load capacity
with low shaft torsional friction. A tilt column is
also available.
