349 Effects
Double Size
Appe
ndix
117: St. Pitch Shifter
(Stereo Pitch Shifter)
This is a stereo pitch shifter. The pitch shift amount for the left
and right channels can be reversed from each other.
a: L/R Pitch
When you select Up/Down for this parameter, the pitch shift
amount for the right channel will be reversed. If the pitch shift
amount is positive, the pitch of the left channel is raised, and the
pitch of the right channel is lowered.
118: St. PitchShift BPM
(Stereo Pitch Shifter BPM)
This stereo pitch shifter enables you to set the delay time to
match the song tempo.
a
Mode
Slow, Medium,
Fast Switches Pitch Shifter mode
L/R Pitch
Normal,
Up/Down Determines whether or not the L/R
pitch shift amount is inverted
b
Pitch Shift [1/
2tone]
–24...+24
Sets the pitch shift amount in steps
of a semitone
Src Off...Tempo
Selects the modulation source of
pitch shift amount
Amt –24...+24
Sets the modulation amount of
pitch shift amount
c
Fine [cents] –100...+100
Sets the pitch shift amount in steps
of one cent
Amt –100...+100
Sets the modulation amount of
pitch shift amount
d L Delay [msec] 0...2000
Sets the delay time for the left
channel
e R Delay [msec] 0...2000
Sets the delay time for the right
channel
f
Feedback –100...+100
Sets the feedback amount
High Damp [%] 0...100
Sets the damping amount in the
high range
g
Feedback
Position
Pre, Post Switches the feedback connection
Spread –100...+100
Sets the width of the stereo image
of the effect sound
h
Input Level
Dmod [%]
–100...+100
Sets the modulation amount of the
input level
Src Off...Tempo
Selects the modulation source for
the input level
i
Wet/Dry
Dry, 1:99...99:1,
Wet Balance between the wet and dry
signal
Src Off...Tempo
Table , “Dynamic Modulation
sources,” on page 283
Amt –100...+100 Amount of modulation source
Left
Right
Feedback Spread
FX Amt
FX Amt
Stereo In - Stereo Out
High Damp
High Damp
Input Level
Input Level
Feedback Position
Pre
Pre
Post
Post
Delay Pitch Shifter
Delay Pitch Shifter
a
Mode
Slow, Medium,
Fast Switches Pitch Shifter mode
L/R Pitch
Normal,
Up/Down Determines whether or not the L/R
pitch shift amount is inverted
b
Pitch Shift [1/
2tone]
–24...+24
Sets the pitch shift amount in steps
of a semitone
Src Off...Tempo
Selects the modulation source of
pitch shift amount
Amt –24...+24
Sets the modulation amount of
pitch shift amount
c
Fine [cents] –100...+100
Sets the pitch shift amount in steps
of one cent
Amt –100...+100
Sets the modulation amount of
pitch shift amount Sets the
modulation amount of pitch shift
amount
d
BPM
MIDI,
40.00...
300.00 MIDI syncs to the system tempo; 40–
300 sets the tempo manually for this
individual effect
Time Over? L ---, OVER!
Display the error message if the left
channel delay time exceeds the
upper limit
R ---, OVER!
Display the error message if the
right channel delay time exceeds
the upper limit
e
L Delay Base
Note
r...w
Selects the type of notes to specify
the left channel delay time
Times x1...x32
Sets the number of notes to specify
the left channel delay time
f
R Delay Base
Note
r...w
Selects the type of notes to specify
the right channel delay time
Times x1...x32
Sets the number of notes to specify
the right channel delay time
g
Feedback
Position
Pre, Post Switches the feedback connection
Spread –100...+100
Sets the width of the stereo image
of the effect sound
h
Feedback –100...+100
Sets the feedback amount
High Damp [%] 0...100
Sets the damping amount in the
high range
i
Input Level
Dmod [%]
–100...+100
Sets the modulation amount of the
input level
Src Off...Tempo
Selects the modulation source for
the input level
j
Wet/Dry
Dry, 1:99...99:1,
Wet Balance between the wet and dry
signal
Src Off...Tempo
Table , “Dynamic Modulation
sources,” on page 283
Amt –100...+100 Amount of modulation source
Tempo
BPM
BPM Base Note x Times
Base Note x Times
Left
Right
Feedback Spread
FX Amt
FX Amt
Stereo In - Stereo Out
High Damp
High Damp
Input Level
Input Level
Feedback Position
Pre
Pre
Post
Post
Delay Pitch Shifter
Delay Pitch Shifter
