319 Effects
Delay
Appe
ndix
a: Control Target
This parameter selects no level control, delay output control
(effect balance), or feedback amount control.
a: Polarity
b: Threshold
b: Offset
c: Attack
d: Release
The “Offset” parameter specifies the value for the “Control Tar-
get” parameter (that is set to None), expressed as the ratio rela-
tive to the parameter value (the “Wet/Dry” value with “Control
Target”=Output level, or the “Feedback” value with “Control
Target”=Feedback).
When “Polarity” is positive, the “Control Target” value is
obtained by multiplying the parameter value by the “Offset”
value (if the input level is below the threshold), or equals the
parameter value if the input level exceeds the threshold.
When “Polarity” is negative, Control Target value equals the
parameter value if the input level is below the threshold, or is
obtained by multiplying the parameter value by the “Offset”
value if the level exceeds the threshold.
The “Attack” and “Release” parameters specify attack time and
release time of delay level control.
61: St. AutoPanningDly
(Stereo Auto Panning Delay)
This stereo delay effect pans the delay sound left and right using
the LFO.
Dynamic Delay
Threshold
Dry
Envelope
Wet
Target=Output Level
Polarity= (–)
Wet
Target=Output Level
Polarity= (+)
Delay Time
Time
(Ducking Delay)
Release
Attack
Level
a
L Delay Time
[msec]
0.0...1360.0
Sets the delay time for the left
channel
L Feedback –100...+100
Sets the feedback amount for the
left channel
b
R Delay Time
[msec]
0.0...1360.0
Sets the delay time for the right
channel
R Feedback –100...+100
Sets the feedback amount for the
right channel
c
High Damp [%] 0...100
Sets the damping amount in the
high range
Low Damp [%] 0...100
Sets the damping amount in the low
range
d
LFO Waveform Triangle, Sine Selects the LFO Waveform
LFO Shape –100...+100
Changes the curvature of the LFO
Waveform
e Phase [degree] –180...+180
Sets the LFO phase difference
between the left and right
f
Panning Freq
[Hz]
0.02...20.00 Sets the panning speed
g
MIDI Sync Off, On
Switches between using the
frequency of the panning speed and
using the tempo and notes
BPM
MIDI,
40.00...
300.00 MIDI syncs to the system tempo; 40–
300 sets the tempo manually for this
individual effect
Base Note r...w
Selects the type of notes to specify
the delay time for the panning
speed
Times x1...x32
Sets the number of notes to specify
the delay time for the panning
speed
h
Panning Depth 0...100 Sets the panning width
Src Off...Tempo
Selects the modulation source for
the panning width
Amt –100...+100
Set the modulation amount of the
panning width
i
Wet/Dry
Dry, 1:99...99:1,
Wet Balance between the wet and dry
signal
Src Off...Tempo
Table , “Dynamic Modulation
sources,” on page 283
Amt –100...+100 Amount of modulation source
Left
Right
FX Amt
FX Amt
Stereo In - Stereo Out
LFO Phase
LFO Shape
Pan
Pan
LFO: Tri / Sin
Depth
Delay
Delay
High Damp Low Damp
High Damp Low Damp
Feedback
