PLX8x-EIP-61850 ♦ Communication Gateway Configuring the PLX8x-EIP-61850 Gateway
Server to
IEC 61850 Client User Manual
ProSoft Technology, Inc. Page 15 of 167
July 2, 2015
2 Configuring the PLX8x-EIP-61850 Gateway
In This Chapter
 Connecting Your PC to the Gateway ..................................................... 15
 Setting a Temporary IP Address in the Gateway ................................... 16
 Creating a New Project in the Configuration Manager .......................... 17
 Exporting a Project from the Configuration Manager ............................. 18
 Importing a Project into the Configuration Manager .............................. 19
 Configuring the Gateway EtherNet/IP Adapter ...................................... 19
 Adding EtherNet/IP Device .................................................................... 21
 Importing IEDs Files .............................................................................. 21
 Creating the IED Network ...................................................................... 24
 Mapping Data Attributes from IEDs to the Gateway .............................. 25
 Mapping Tags in the Gateway to EtherNet/IP ....................................... 34
 Validating the Configuration .................................................................. 37
 Downloading the Configuration File to the Gateway .............................. 38
 Uploading the Configuration from the Gateway ..................................... 39
 Exporting the IED Add-On Instructions for RSLogix 5000 ..................... 40
 Exporting the EIP-61850 Configuration to a File ................................... 40
 Importing an Updated IED File .............................................................. 41
To configure the PLX8x-EIP-61850 gateway, follow these topics in the same
order as they appear in this chapter.
The reason you import the IEDs before you configure the EtherNet/IP device is
that the ProSoft 61850 Configuration Manager takes steps to assist with the
EtherNet/IP configuration after you set up the IEDs in the EIP-61850
Configuration Manager.
2.1 Connecting Your PC to the Gateway
You can use the Ethernet cable included with the gateway to connect your PC to
the gateway
’s Ethernet port. If your gateways has two Ethernet ports, refer to
sections 2.2 through 2.6. Later, you can connect the gateway to a switch, through
a patch cable, allowing the IEDs, gateway, and ControlLogix PAC, or
CompactLogix PAC to all operate on the same network.
Once connected, you use the ProSoft Discovery Service to locate the gateway
and assign a temporary IP address (refer to Setting a Temporary IP Address in
the Gateway on page 16). You can set a permanent IP address when you
configure the module (refer to Configuring the Gateway EtherNet/IP Adapter on
page 19).
