6 Page and Menu Selection
SMA Solar Technology AG
44
HoMan_Portal-BA-en-17
User Manual
Details Area
This area contains the power values of the displayed diagram as 15-minute mean values.
Logbook Area
This area contains messages from selected devices and associated higher-level system messages.
Week
• Diagram preview: Preview of diagrams with the development of PV
system yields for individual weeks
Tip: If you move the cursor over a week in the diagram, the total yield of
the PV system for this week is shown.
• Large diagram:
– Power value curve as 15-minute mean values of selected devices for
the selected week.
– Bottom right in the diagram*: Total yield of the PV system for the
selected week
Month
• Diagram preview: Preview of diagrams with the yield values of the PV
system for each month in days
Tip: If you move the cursor over a month in the diagram, the total yield
of the PV system for this month is shown.
• Large diagram:
– Yield values of selected devices for the selected month in days
– Bottom right in the diagram*: Total yield of the PV system for the
selected month
Year
• Diagram preview: Preview of diagrams with the yield values of the PV
system for each year in months
Tip: If you move the cursor over a year in the diagram, the total yield of
the PV system for this year is shown.
• Large diagram:
– Yield values of selected devices for the selected year in months
– Bottom right in the diagram*: Total yield of the PV system for the
selected year
Total
• Large diagram:
– Yield values of selected devices for individual years
– Bottom right in the diagram*: Total yield of the PV system for all
years together
* Only displayed if the Complete PV system checkbox is activated in Device selection.
Tab
Content
