6 Page and Menu Selection SMA Solar Technology AG
42 HoMan_Portal-BA-en-17 User Manual
6.3 Analysis
On the Analysis page, you can compare the power and yield values of individual inverters with one
another or with the complete system.
Figure 4: Analysis page (example)
Position Explanation
A Device selection area
B Tabs
C Diagram preview*
The diagram preview is divided into sections by lines. If you select a section in the
diagram preview, the content is shown in the large diagram.
D Large diagram
Tip: If you move the mouse on to the diagram, the value from the Details area is
shown next to the cursor.
E Details area
F Logbook area
