HEIDENHAIN iTNC 530 (340 49x-02) ISO programming - Manual (Page 475)

HEIDENHAIN iTNC 530 475
1
0
.5 Nesting
Repeating a subprogram
Example NC blocks
Program execution
1 Main program UPGREP is executed up to block N110.
2 Subprogram 2 is called and executed.
3 Program section between block N120 and block N100 is repeated
twice. Subprogram 2 is repeated twice.
4 Main program SUBPGREP is executed once from block N130 to
block N190. End of program.
%UPGREP G71 *
...
N100 G98 L1 * Beginning of program section repeat 1
N110 L2.0 * Subprogram call
N120 L1.2 * Program section between this block and G98 L1
... (block N100) is repeated twice
N190 G00 G40 Z+100 M2 * Last block of the main program with M2
N200 G98 L2 * Beginning of subprogram
...
N280 G98 L0 * End of subprogram
N99999999 %UPGREP G71 *
