Operating the Transceiver System
The CopperHead 3400 Base Station Digital Display
DIAG/POWER POWR Indicates the display is in the POWER sub-mode
DIAG/POWER OK Indicates that the item is in an OK State
DIAG/POWER Exception
DIAG/POWER ERR Instead of OK, the display will show ERR if a power level is outside of
normal – ERR is followed by a Hexadecimal code.
Please note the error code and contact support at Grass Valley, a Belden
Brand .
DIAGNOSTIC MODE Microcontroller Board Revision Version (REV)
DIAG/REV A quick push of the Display Mode selector advances to the Power (POWR)
diagnostic sub-mode. This sub-mode displays the microcontroller
firmware revision of every board in the Base Station that has a
microcontroller.
DIAG/REV REV Initial display of REV after Display Mode selector being advances
DIAG/REV DISP Indicates the Display microcontroller board is revision is being queried
DIAG/REV REV Indicates that sub-mode is REV
DIAG/REV REVC Indicates that the REV for the DISP board is REVC
DIAG/REV VBS Indicates the VBS microcontroller board is revision is being queried
DIAG/REV REV Indicates that sub-mode is REV
DIAG/REV REVA Indicates that the REV for the VBS board is REVA
DIAG/REV BASE Indicates the Base Station main microcontroller board is revision is being
queried
DIAG/REV REV Indicates that sub-mode is REV
DIAG/REV REVA Indicates that the REV for the BASE board is REVA
DIAG/REV AUD Indicates the audio microcontroller board is revision is being queried
DIAG/REV REV Indicates that sub-mode is REV
DIAG/REV REVA Indicates that the REV for the AUD board is REVA
DIAG/REV PS Indicates the power supply microcontroller board is revision is being
queried
DIAG/REV REV Indicates that sub-mode is REV
DIAG/REV REVD Indicates that the REV for the DISP board is REVD
This display cycle repeats until the Display Mode selector is pushed
DIAGNOSTIC MODE Camera Unit Error Status (CAM)
Display Mode
Typical
Readout
Base Station Digital Display Activity Explanation
