45
Connecting the Transceiver System
Prior to connecting your CopperHead 3400, please ensure that each of the required cables
is available for use. This includes standard video, audio, and data cables, as well as custom
multi-pin cable sets required for your particular installation.
Refer to Multi-Pin Connectors: Suggested Wiring on page 92 for information regarding
cables, signals and custom multi-pin cable fabrication.
Connections between the Base Station and the Camera Unit . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Connections to the CopperHead 3400 Base Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Connections to the CopperHead 3400 Camera Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Camera Unit Connection Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
