Appendix C: Code 128 Bar Code

A.1 Description of the CODE128 Bar Code

Code 128 bar codes can encode 128 unique ASCII characters, 2-digit numerals and special

characters by using one bar code character that is defined by combining code set A, code set B and

code set C. Each code set is used for representing the following characters:

· Code set A: ASCII characters 00H to 5FH

· Code set B: ASCII characters 20H to 7FH

· Code set C: 2-digit numeral characters using one character (100 numerals from 00 to 99)

The following special characters are also available in CODE128:

· SHIFT characters

In code set A, the character just after SHIFT is processed as a character for code set B. In code set

B, the character just after SHIFT is processed as a character for code set A. The character recovers

the previous code set before SHIFT when starting from the second character. SHIFT characters are

used only for switching between code set A and code set B, but cannot make the current code set

enter or exit code set c status.

· Code set selection character (CODE A, CODE B, CODE C).

This character switches the following code set to code set A, B, or C.

· Function character (FNC1, FNC2, FNC3, FNC4)

Code set C allows only FNC1.
