XSAT7080 X-Band Transceiver Revision 0
5-25W Installation MN/XSAT7080.IOM
A–17
Item Part No. Nomenclature QTY
1 SW/COAX-N-F-Sealed Switch COAX N-FE 1
2 RF/A8430N RF-ATTEN, DC, 30 dB 1
3 HW/M4X.07X8MMPHMS Screw, Panhead 4
4 HW/M4LOCK Washer, Lock 4
5 CA/RF0097 Cable, Output RF 2
6 CN/CXNPLUGCAP Plug Cap, Non-shorting 1
Figure A-15. TX/Remote Switch Assembly, AS/0503
