Comtech EF Data XSAT-7080 User Manual
Page 96
XSAT7080 X-Band Transceiver
Revision 0
5-25W Installation
MN/XSAT7080.IOM
A–14
Item
Part No.
Nomenclature
QTY
1
CA/RF0097
Cable, Output RF
4
2
CA/WR0051
Cable, Control-LNA Switch
1
3
CA/WR0052
Cable, Control-TX Switch
1
4 CA/WR0053 Cable,
Communication
1
5 CA/WR0053 Cable,
Communication
1
Figure A-12. Cable Kit, AS/0440
