XSAT7080 X-Band Transceiver Revision 0
Remote Control MN/XSAT7080.IOM
4-20
Parameter
Type
Command
(Instruction
Code and
qualifier) Arguments
for
Command
or
Response
to Query
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Response to
Command
(Slave to Master)
Query
(Instruction
code and
qualifier)
Response to Query
(Slave to Master)
Concise
Alarm Status N/A 18 bytes,
numerical Query only.
Used to Query the Alarm status of the XSAT
Example: CMS=abcdefghijklmnopqr’cr’’lf’
where: a thru n = 0 or 1, 0 = OK 1 = FT
a = 24V Power Supply Alarm
b = 20V Power Supply Alarm
c = 12V Power Supply Alarm
d = 10V Power Supply Alarm
e = +5V Power Supply Alarm
f = -5V Power Supply Alarm
g = Tx Synthesizer Lock Detect Alarm
h = Tx IFLO Lock Detect Alarm
I = Rx Synthesizer Lock Detect Alarm
j = Rx IFLO Lock Detect Alarm
k = Reference Lock Detect Alarm
l = LNA Current Alarm
m = Fan Current Alarm
n = Temperature Alarm
o = HPA Thermal Shutdown Alarm
p = Internal IIC-bus Alarm
q = EEPROM checksum Alarm
r = NVRAM/RTC Low Battery Alarm
N/A CAS? CAS=x….x (see description for
details of arguments)
Summary
Fault Status N/A 1 byte,
alpha
numerical
Query only.
Used to Query the status of the XSAT Summary
Fault Relay.
Example: SFS=0’cr’’lf’
where: 0 = OK 1 = FT N/A SFS? SFS=x (see description for details
of arguments)
