XSAT7080 X-Band Transceiver Revision 0
System Operation MN/XSAT7080.IOM
3–2
3.1.2 C
ONNECTOR
J5: COMM, R
EMOTE COMMUNICATIONS PORT
.
Mating connector: ITT: KPT06J14-19P or MS3116J14-19P
Connections, see the following table:
Pin Signal I/O Notes
A EIA -485 +RX Input XSAT Receive Line
B EIA -485 –RX Input XSAT Receive Line Compliment
C EIA -485 TX+ Output XSAT Transmit Line
D EIA -485 TX- Output XSAT Transmit Line Compliment
E EIA -232 Rd Input XSAT Receive Line
F REDUNDANT FAULT Input Redundant Controller Status Input
G EIA -232 Td Output XSAT Transmit Line
H AUXCOM Rd Input Auxiliary RS232 Rd used with Redundant Controller
J AUXCOM Td Output Auxiliary RS232 Td used with Redundant Controller
K FAULT COMMON Output
L FAULT NORM OPEN Output Open(OK) / Short(Fault)
M FAULT NORM CLOSED Output Short(OK) / Open(Fault)
N ADDRESS SELECT Input Redundant Addressing
P ONLINE STATUS Input Input from Redundant Controller
R +24V AUX Output 24V output to power Redundant Controller
S REDUNDANCY Input Open (stand-alone) / Gnd (Redundancy)
T GROUND Passive
U GROUND Passive
V NO CONNECT
