4-4 SANnet II 200 FC, SATA, and SATA SE Array Installation, Operation, and Service Manual • March 2005
9. Replace the bezel.
Note –
To convert your bezel locks so that the keys can be removed, repeat this
procedure.
4.2 RAID Array Connections
Management is in-band through fibre host connections and out-of-band through the
serial port and Ethernet port on the back of each controller.
4.2.1 SANnet II 200 FC Array Connections
Figure 4-3 identifies the hardware connections on the back of a dual-controller SANnet
II 200 FC array.
