Appendix B Using a Standalone JBOD Array (SANnet II 200 FC Array Only) B-9
Caution – Be careful not to mount the same drive twice if you are not using
multipathing software.
B.7.3 Changing Your SFP Configuration on JBOD Arrays
SANnet II 200 FC JBOD arrays use SFP connectors to attach to Fibre Channel ports
on your host computer. You might need to move or add one or more SFP connectors to
your SANnet II 200 FC JBOD array to connect it to your host computer.
■
To make connections to an empty port, first slide the SFP connector into the port so
that it connects firmly with the chassis. Then plug the fiber-optic cable’s SFP
connector into the duplex jack at the end of the SFP.
■
To remove an SFP connector, make sure no cable is connected to it and then slide it
out from the port.
B.7.4 Connecting the SANnet II 200 FC JBOD Array to a
Host Computer
Use fiber-optic cables to connect one or two HBA ports on the host computer to the
SANnet II 200 FC JBOD array, as shown in Figure B-2 and Figure B-3.
Table B-4 Example of 24 Drives Shown on a 12-Disk SANnet II 200 FC JBOD
Array Connected to a Host Over Two FC Loops
Drive Identifier (First Loop) Drive Identifier (Second Loop)
c1t0d0 c2t0d0
c1t1d0 c2t1d0
c1t2d0 c2t2d0
c1t3d0 c2t3d0
c1t4d0 c2t40d0
c1t5d0 c2t5d0
c1t6d0 c2t6d0
c1t7d0 c2t7d0
c1t8d0 c2t8d0
c1t9d0 c2t9d0
c1t10d0 c2t10d0
c1t11d0 c2t11d0
