8-4 SANnet II 200 FC, SATA, and SATA SE Array Installation, Operation, and Service Manual • March 2005
8.1.3 Voltage Sensors
Voltage sensors make sure that the array’s voltage is within normal ranges. The voltage
components differ for the SANnet II 200 FC, SATA, and SATA SE arrays. The
following tables describe each voltage sensor.
Table 8-3 Voltage Sensors for FC Arrays
Element
ID
Description Location Alarm Condition
0 Voltage Sensor 0 Left Power Supply (5V) < 4.00V or > 6.00V
1 Voltage Sensor 1 Left Power Supply (12V) < 11.00V or >
13.00V
2 Voltage Sensor 2 Right Power Supply (5V) < 4.00V or > 6.00V
3 Voltage Sensor 3 Right Power Supply (12V) < 11.00V or >
13.00V
4 Voltage Sensor 4 Upper I/O Module (2.5V Local) < 2.25V or > 2.75V
5 Voltage Sensor 5 Upper I/O Module (3.3V Local) < 3.00V or > 3.60V
6 Voltage Sensor 6 Upper I/O Module (Midplane
5V)
< 4.00V or > 6.00V
7 Voltage Sensor 7 Upper I/O Module (Midplane
12V)
< 11.00V or >
13.00V
8 Voltage Sensor 8 Lower I/O Module (2.5V Local) < 2.25V or > 2.75V
9 Voltage Sensor 9 Lower I/O Module (3.3V Local) < 3.00V or > 3.60V
10 Voltage Sensor
10 Lower I/O Module (Midplane
5V) < 4.00V or > 6.00V
11 Voltage Sensor
11 Lower I/O Module (Midplane
12V) < 11.00V or >
13.00V
Table 8-4 Voltage Sensors for SATA and SATA SE Arrays
Element
ID
Description Location Alarm Condition
0 Voltage Sensor 0 Left Power Supply (5V) < 4.86V or > 6.60V
1 Voltage Sensor 1 Left Power Supply (12V) < 11.20V or >
15.07V
2 Voltage Sensor 2 Right Power Supply (5V) < 4.86V or > 6.60V
3 Voltage Sensor 3 Right Power Supply (12V) < 11.20V or >
15.07V
