3-2 SANnet II 200 FC, SATA, and SATA SE Array Installation, Operation, and Service Manual • March 2005
6. Check the list of “Customer-Provided Cables” on page 3-3.
These are required to complete your installation.
Note – You must purchase or provide fiber-optic cables for connecting FC, SATA, and
SATA SE arrays to host servers.
3.2 Checking the Package Contents
Inspect the array package for standard items as well as purchased options before you
begin installation. If any parts are missing or damaged, contact your sales
representative immediately.
3.2.1 Standard Array Packages
Table 3-1 Contents of SANnet II 200 Array Packages
Quantity Item
1 One or more of the following arrays:
• SANnet II 200 FC array, SANnet II 200 SATA array, or SANnet II 200 SATA SE array
with single controller
• SANnet II 200 FC array, SANnet II 200 SATA array, or SANnet II 200 SATA SE array
with dual controllers
• SANnet II 200 FC JBOD, SANnet II 200 FC expansion unit, or SANnet II 200 SATA
expansion unit
1 • Contents Sheet for your array
• Quick installation guide for your array
• To download and print the latest release notes, go to the SANnet II 200 FC, SATA, or
SATA SE array section and to the software section at the following location:
http://www.dothill.com/manuals
1 CD for user documentation
1 Serial null modem cable
1 or 2 25-foot (7.5 m) shielded CAT-5 Ethernet cable (one per controller)
1 Cable adapter, DB9 to DB25
2 DC power cables if you ordered a DC-powered array
2 AC cord locks in a plastic bag if you ordered an AC-powered array
1 AC cable country kit if the array is AC powered
2 Front bezel keys in a plastic bag, to secure the front bezel onto the chassis
Various Purchased options. These options are ordered at the time of purchase and are integrated
into or added to the unit prior to delivery.
