Chapter 8 Troubleshooting Your Array 8-5
8.1.4 Power Supply Sensors
Each SANnet II 200 FC, SATA, and SATA SE array has two fully redundant power
supplies, with load sharing capabilities. The sensors monitor the voltage, temperature,
and fan units in each power supply.
8.2 Silencing Audible Alarms
An audible alarm indicates that either a component in the array has failed or a specific
controller event has occurred. Error conditions and controller events are reported by
event messages and event logs. Component failures are also indicated by LED activity
on the array.
4 Voltage Sensor 4 Upper I/O Module (1.8V) < 1.71V or > 1.89V
5 Voltage Sensor 5 Upper I/O Module (2.5V) < 2.25V or > 2.75V
6 Voltage Sensor 6 Upper I/O Module (3.3V) < 3.00V or > 3.60V
7 Voltage Sensor 7 Upper I/O Module (1.812V) 1 < 1.71V or > 1.89V
8 Voltage Sensor 8 Upper I/O Module (Midplane 5V) < 4.00V or > 6.00V
9 Voltage Sensor 9 Upper I/O Module (Midplane 12V) < 11.00V or >
13.00V
10 Voltage Sensor 10 Lower I/O Module (1.8V) < 1.71V or > 1.89V
11 Voltage Sensor 11 Lower I/O Module (2.5V) < 2.25V or > 2.75V
12 Voltage Sensor 12 Lower I/O Module (3.3V) < 3.00V or > 3.60V
13 Voltage Sensor 13 Lower I/O Module (1.812V) 1 < 1.71V or > 1.89V
14 Voltage Sensor 14 Lower I/O Module (Midplane 5V) < 4.00V or > 6.00V
15 Voltage Sensor 15 Lower I/O Module (Midplane 12V) < 11.00V or >
13.00V
1. 5V on Rev 28 boards.
Table 8-5 Power Supply Sensors for FC, SATA, and SATA SE Arrays
Element ID Description Location Alarm Condition
0 Left Power Supply 0 Left viewed from
the rear Voltage, temperature,
or fan fault
1 Right Power Supply 1 Right viewed from
the rear
Voltage, temperature,
or fan fault
Table 8-4 Voltage Sensors for SATA and SATA SE Arrays (Continued)
Element
ID
Description Location Alarm Condition
