Chapter 8 Troubleshooting Your Array 8-3
8.1.2 Temperature Sensors
Extreme high and low temperatures can cause significant damage if they go unnoticed.
There are twelve temperature sensors at key points in the enclosure.
Table 8-2 Temperature Sensors for FC, SATA, and SATA SE Arrays
Element
ID
Description Location Alarm Condition
0 Temperature Sensor 0 Drive Midplane Left < 32 ° F (0° C) or > 131° F
(55 ° C)
1 Temperature Sensor 1 Drive Midplane Left < 32 ° F (0° C) or > 131° F
(55 ° C)
2 Temperature Sensor 2 Drive Midplane Center < 32 ° F (0° C) or > 131° F
(55 ° C)
3 Temperature Sensor 3 Drive Midplane Center < 32 ° F (0° C) or > 131° F
(55 ° C)
4 Temperature Sensor 4 Drive Midplane Right < 32 ° F (0° C) or > 131° F
(55 ° C)
5 Temperature Sensor 5 Drive Midplane Right < 32 ° F (0° C) or > 131° F
(55 ° C)
6 Temperature Sensor 6 Upper I/O Module < 32 ° F (0° C) or > 140° F
(60 ° C)
7 Temperature Sensor 7 Upper I/O Module < 32 ° F (0° C) or > 140° F
(60 ° C)
8 Temperature Sensor 8 Lower I/O Module < 32 ° F (0° C) or > 140° F
(60 ° C)
9 Temperature Sensor 9 Lower I/O Module < 32 ° F (0° C) or > 140° F
(60 ° C)
10 Temperature Sensor 10 Power Supply 0 < 32 ° F (0° C) or > 140° F
(60 ° C)
11 Temperature Sensor 11 Power Supply 1 < 32 ° F (0° C) or > 140° F
(60 ° C)
