Chapter 2 Site Planning 2-7
Table 2-4 Site Preparation Worksheet
Rackmounting Customers must ensure that the appropriate service outlets are available for
installation. Requirements vary.
• Will the array be rackmounted? Yes / No
• Is the rack supplied by Dot Hill, Inc.? Yes / No
• If yes, include Dot Hill model number: ____
• If not, make/model: _____________________ /_____________________
• Does the rack mount have:
• Front and back? If so, depth? ______
• Center/Telco? ______
• What cable lengths are required? _________________
• Are there any power strips or power sequencers in the rack? Yes / No
• Are they supplied by Dot Hill, Inc.? Yes / No
• If yes, part number: ___________
• If not, quantity of plugs/outlets required: __________ / __________
IP address Array IP address: ______.______.______.______
Array network mask: ______.______.______.______
Cabling Fiber-optic cable lengths to connect to hosts: _______________
