4-1
CH A P T E R 4
Connecting Your Array
This chapter describes procedures for cabling a FC, SATA, or SATA SE array and for
connecting an array to power and to network devices.
The following topics are covered in this chapter:
■
“Converting Your Front Bezel Locks So the Keys Cannot Be Removed” on
page 4-2
■
“RAID Array Connections” on page 4-4
■
“SANnet II 200 FC Array Connections” on page 4-4
■
“SANnet II 200 SATA Array Connections” on page 4-5
■
“SANnet II 200 SATA SE Array Connections” on page 4-7
■
“Connecting the Chassis to AC Power Outlets” on page 4-7
■
“Connecting the Chassis to DC Power Outlets” on page 4-9
■
“Cabling to Expansion Units” on page 4-11
■
“Setting Loop IDs on Expansion Units” on page 4-13
■
“Powering Up and Checking LEDs” on page 4-16
■
“Reviewing Channels, Ports, and SFPs” on page 4-16
■
“Drive Port Connectivity in a Dual-Controller Array” on page 4-17
■
“Host Port Connectivity in a Dual-Controller Array” on page 4-19
■
“Default SFP Placement” on page 4-21
■
“Changing Your SFP Configuration” on page 4-24
■
“Establishing Communications With An Array” on page 4-25
■
“Configuring a Host COM Port to Connect to a RAID Array” on page 4-26
■
“Manually Setting a Static IP Address” on page 4-27
■
“Setting Up Out-of-Band Management Over Ethernet” on page 4-28
■
“Scaling a SANnet II 200 Fibre Channel Array Into a High-Capacity
Configuration” on page 4-29
■
“Adding an Expansion Unit to an Existing RAID Array” on page 4-30
■
“Connecting Ports to Hosts” on page 4-31
■
“Power-On Sequence” on page 4-32
■
“Powering Off the Array” on page 4-33
