Pin Assignments
MVME6100 Single Board Computer Installation and Use (6806800D58H) 93
5.2.5 VMEbus P1 Connector
The VME P1 connector is an 160-pin DIN. The P1 connector provides power and VME signals for
24-bit address and 16-bit data. The pin assignments for the P1 connector is as follows:
Table 5-12 VMEbus P1 Connector Pin Assignments
ROW Z ROW A ROW B ROW C ROW D
1 Reserved D00 BBSY* D08 Reserved 1
2 GND D01 BCLR* D09 Reserved 2
3 Reserved D02 ACFAIL* D10 Reserved 3
4 GND D03 BG0IN* D11 Reserved 4
5 Reserved D04 BG0OUT* D12 Reserved 5
6 GND D05 BG1IN* D13 Reserved 6
7 Reserved D06 BG1OUT* D14 Reserved 7
8 GND D07 BG2IN* D15 Reserved 8
9 Reserved GND BG2OUT* GND Reserved
(Geographical
Address, parity) 9
10 GND SYSCLK BG3IN* SYSFAIL* Reserved (GA0) 10
11 Reserved GND BG3OUT* BERR* Reserved (GA1) 11
12 GND DS1* BR0* SYSRESET* Reserved 12
13 Reserved DS0* BR1* LWORD* Reserved (GA2) 13
14 GND WRITE* BR2* AM5 Reserved 14
15 Reserved GND BR3* A23 Reserved (GA3) 15
16 GND DTACK* AM0 A22 Reserved 16
17 Reserved GND AM1 A21 Reserved (GA4) 17
18 GND AS* AM2 A20 Reserved 18
19 Reserved GND AM3 A19 Reserved 19
20 GND IACK* GND A18 Reserved 20
21 Reserved IACKIN* SERA A17 Reserved 21
22 GND IACKOUT* SERB A16 Reserved 22
