Pin assignments – Artesyn MVME6100 Single Board Computer Installation and Use (June 2014) User Manual
Page 86
Pin Assignments
MVME6100 Single Board Computer Installation and Use (6806800D58H)
86
3
PMC0_3 (P2-C2)
PMC0_4 (P2-A2)
4
5
PMC0_5 (P2-C3)
PMC0_6 (P2-A3)
6
7
PMC0_7 (P2-C4)
PMC0_8 (P2-A4)
8
9
PMC1 _9 (P2-C5)
PMC0_10 (P2-A5)
10
11
PMC0_11 (P2-C6)
PMC0_12 (P2-A6)
12
13
PMC0_13 (P2-C7)
PMC0_14 (P2-A7)
14
15
PMC0_15 (P2-C8)
PMC0_16 (P2-A8)
16
17
PMC0_17 (P2-C9)
PMC0_18 (P2-A9)
18
19
PMC0_19 (P2-C10)
PMC0_20 (P2-A10)
20
21
PMC0_21 (P2-C11)
PMC0_22 (P2-A11)
22
23
PMC0_23 (P2-C12)
PMC0_24 (P2-A12)
24
25
PMC0_25 (P2-C13)
PMC0_26 (P2-A13)
26
27
PMC0_27 (P2-C14)
PMC0_28 (P2-A14)
28
29
PMC0_29 (P2-C15)
PMC0_30 (P2-A15)
30
31
PMC0_31 (P2-C16)
PMC0_32 (P2-A16)
32
33
PMC0_33 (P2-C17)
PMC0_34 (P2-A17)
34
35
PMC0_35 (P2-C18)
PMC0_36 (P2-A18)
36
37
PMC0_37 (P2-C19)
PMC0_38 (P2-A19)
38
39
PMC0_39 (P2-C20)
PMC0_40 (P2-A20)
40
41
PMC0_41 (P2-C21)
PMC0_42 (P2-A21)
42
43
PMC0_43 (P2-C22)
PMC0_44 (P2-A22)
44
45
PMC0_45 (P2-C23)
PMC0_46 (P2-A23)
46
47
PMC0_47 (P2-C24)
PMC0_48 (P2-A24)
48
49
PMC0_49 (P2-C25)
PMC0_50 (P2-A25)
50
51
PMC0_51 (P2-C26)
PMC0_52 (P2-A26)
52
53
PMC0_53 (P2-C27)
PMC0_54 (P2-A27)
54
55
PMC0_55 (P2-C28)
PMC0_56 (P2-A28)
56
Table 5-6 PMC Slot 1 Connector (J14) Pin Assignments (continued)
Pin
Signal
Signal
Pin
