Pin Assignments
MVME6100 Single Board Computer Installation and Use (6806800D58H) 101
5.3.1 SCON Header (J7)
A 3-pin planar header allows the choice for auto/enable/disable SCON VME configuration. A
jumper installed across pins 1 and 2 configures for SCON always enabled. A jumper installed
across pins 2 and 3 configures for SCON disabled. No jumper installed configures for auto
SCON. The pin assignments for this connector are as follows:
5.3.2 Boundary Scan Header (J8)
The 14-pin boundary scan header provides an interface for programming the on-board PLDs
and for boundary scan testing/debug purposes. The pin assignments for this header are as
follows:
Table 5-16 SCON Header (J7) Pin Assignments
Pin Signal
1 SCONEN_L
2 GND
3 SCONDIS_L
Table 5-17 Boundary Scan Header (J8) Pin Assignments
Pin Signal Signal Pin
1 TRST_L GND 2
3 TDO GND 4
5 TDI GND 6
7 TMS GND 8
9 TCLK GND 10
11 NC CPU_BSCAN_L 12
13 AW_L GND 14
