6 processor jtag/cop header (j42), Table 5-21, Processor jtag/cop header (j42) – Artesyn MVME6100 Single Board Computer Installation and Use (June 2014) User Manual
Page 104: Pin assignments
Pin Assignments
MVME6100 Single Board Computer Installation and Use (6806800D58H)
104
5.3.6
Processor JTAG/COP Header (J42)
There is one standard 16-pin header that provides an interface for the RISCWatch function. The
pin assignments for this header are as follows:
Some signals are actually resistor buffered versions of the named signal.
Table 5-21 Processor JTAG/COP (RISCWatch) Header (J42) Pin Assignments
Pin
Signal
Signal
Pin
1
CPU_TDO
CPU_QACK_L
2
3
CPU_TDI
CPU_TRST_L
4
5
CPU_QREQ_L
PU CPU_VIO
6
7
CPU_TCK
OPT PU CPU_VIO
8
9
CPU_TMS
NC
10
11
CPU_SRST_L
OPTPD_GND
12
13
CPU_HRST_L
KEY (no pin)
14
15
CPU_CKSTPO_L
GND
16
