Chapter 5

MVME6100 Single Board Computer Installation and Use (6806800D58H)

77

Pin Assignments

5.1

Overview

This chapter provides pin assignments for various headers and connectors on the MMVE6100
single-board computer.

Gigabit Ethernet Connectors (J9, J93)

PCI Mezzanine Card (PMC) Connectors (J11 – J14, J21 – J24)

COM1 Connector (J19)

VMEbus P1 Connector

VMEbus P2 Connector (IPMC Mode)

The following headers are described in this chapter:

SCON Header (J7)

Boundary Scan Header (J8)

PMC/IPMC Selection Headers (J10, J15 – J18, J25 – J28)

COM2 Header (J29)

Front/Rear Ethernet and Transition Module Options Header (J30)

Processor JTAG/COP Header (J42)

5.2

Connectors

The following tables provide a brief description of the connector, the pin assignments, and
signal descriptions for standard and nonstandard connectors on the MVME6100.
