background image

Pin Assignments

MVME6100 Single Board Computer Installation and Use (6806800D58H)

82

The pin assignments for these connectors are as follows.

Table 5-3 PMC Slot 1 Connector (J11) Pin Assignments

Pin

Signal

Signal

Pin

1

TCK

-12V

2

3

GND

INTA#

4

5

INTB#

INTC#

6

7

PMCPRSNT1#

+5V

8

9

INTD#

PCI_RSVD

10

11

GND

+3.3Vaux

12

13

CLK

GND

14

15

GND

PMCGNT1#

16

17

PMCREQ1#

+5V

18

19

+3.3V (VIO)

AD31

20

21

AD28

AD27

22

23

AD25

GND

24

25

GND

C/BE3#

26

27

AD22

AD21

28

29

AD19

+5V

30

31

+3.3V (VIO)

AD17

32

33

FRAME#

GND

34

35

GND

IRDY#

36

37

DEVSEL#

+5V

38

39

PCIXCAP

LOCK#

40

41

PCI_RSVD

PCI_RSVD

42

43

PAR

GND

44

45

+3.3V (VIO)

AD15

46

47

AD12

AD11

48

49

AD09

+5V

50
