Site Preparation
Centellis 2000 Shelf Release 3.0 Installation and Use (6806800L99G) 78
2.4 Dimensions and Weight
The table below lists the dimensions and weight of the shelf and system components.
2.5 Mounting Options
You can install the system in a standard 19" ANSI rack using the front integrated chassis
mounting flanges.
Table 2-5 Dimensions and Weight of System and Components
Component
Dimensions
w x h x d in mm
Weight in kg
Shelf, including two fan trays, two PSUs/PEMs, air filter 483 x 132 x 420 12.00
AC PSU 90 x 63 x 303 1.33
DC PEM 90 x 63 x 303 1.37
Front fan tray 134 x 92 x 337 0.52
Rear fan tray 134 x 92 x 210 0.57
MF106 155 x 21 x 145 0.14
User card 126 x 19 x 114 N/A
Front filler panel 30 x 350 x 296 0.80
Rear filler panel 30 x 350 x 90 0.30
