BINDER KB 23 - Manual (Page 55)

KB (E3.1 + E5.1) 11/2014 page 55/100
Normal Display
Display 1 shows e.g. 19.8 (actual temperature value)
Display 2 shows e.g. 15.05.06 13:52 - -
(actual date and time, actual state of week program timer
channel 1: Off, channel 2: Off)
Press down key
for 5 sec
Display 1 shows e.g. 0000
Display 2 shows PROGRAM EDITOR (you are in the program editor)
Press down key
for 5 sec
Display 1 shows 0000
Display 2 shows WEEK PROG. EDITOR (you are in the week program editor)
Press program key
Display 1 shows 0000
Display 2 shows UserCod? 0000 (enter user code, display flashes)
Enter the user code using arrow keys
e.g. 0001 (basic setting, adjustable in the
user level, chap. 10).
Value is shown in both displays.
Automatically forward after 2 sec
Display 1 shows 0000
Display 2 shows Monday
(selection of day of the week)
(actual selection: Monday)
Select the first day of the week ( Monday)
with key
Day of the week is shown in display 2.
Press program key
Display 1 shows 0000
Display 2 shows Shiftpt. (no function)
Press program key
Display 1 shows 0000
Display 2 shows Shiftpt. 1
(selection of the shift point)
(actual shift point: 1)
Select shift point 1 with key
Value is shown in display 2.
Press program key
Display 1 shows e.g. --.-- (time of the selected shift point)
Display 2 shows S1: --:--
(actual selection of the shift point: S1)
(actual setting: shift point not programmed)
Press program key
Display 1 shows 06.00 (time of the selected shift point)
Display 2 shows Time 06:00
(entry of time of the selected shift point)
(actual setting: 6.00, i.e. 6 a.m.)
Enter the time 06:00 using arrow keys
Value is shown in display 2.
