Technical Specifications
120
IQS-1600
GENERAL SPECIFICATIONS
IQS-1710/1720
and
IQS-1613/1623/1643
IQS-1613W/1623W/1643W
IQS-1712X/1722X
OHS-1713W-PL
OHS-1713-UH
External trigger
input voltage (V)
0 to 5 (TTL)
0 to 5 (TTL)
N/A
N/A
N/A
Size (H x W x D)
125 mm x 36 mm x 282 mm
125 mm x 36 mm x 282 mm
125 mm x 36 mm x 282 mm
43 mm x 66 mm x 151 mm
42 mm x 79 mm x 190 mm
(4
15
/
16
in x 1
7
/
16
in x 11
1
/
8
in)
(4
15
/
16
in x 1
7
/
16
in x 11
1
/
8
in)
(4
15
/
16
in x 1
7
/
16
in x 11
1
/
8
in)
(1
11
/
16
in x 2
5
/
8
in x 5
15
/
16
in)
(1
5
/
8
in x 3
1
/
8
in x 7
1
/
2
in)
Weight
0.7 kg (1.5 lb)
0.7 kg (1.5 lb)
0.58 kg (1.3 lb)
0.32 kg (0.7 lb)
0.45 kg (1.0 lb)
Temperature
Operating
a
0 °C to 40 °C
0 °C to 40 °C
0 °C to 40 °C
0 °C to 40 °C
0 °C to 40 °C
(32 °F to 104 °F)
(32 °F to 104 °F)
(32 °F to 104 °F)
(32 °F to 104 °F)
(32 °F to 104 °F)
Storage
−35 °C to 70 °C
−35 °C to 70 °C
−40 °C to 70 °C
−40 °C to 70 °C
−40 °C to 70 °C
(
−31 °F to 158 °F)
(
−31 °F to 158 °F)
(
−40 °F to 158 °F)
(
−40 °F to 158 °F)
(
−40 °F to 158 °F)
Analog output
Bandwidth (Hz)
700 k; 700 k; 30 k; 30 k
50 k, 7.5 k, 5 k
2500 (typical)
N/A
N/A
150; 150; (typical)
b
7 k, 1 k, 1 k (typical)
b
Output voltage (V)
0 to 2.15 (typical)
0 to 2.15 (typical)
0 to 4 (typical)
N/A
N/A
Output impedance (
⏐ )
640
640
100 to 150
N/A
N/A
Number of ports
1/1/0
1/1/0
1/2/1
N/A
N/A
Relative humidity
c
0 % to 80 %
0 % to 80 %
0 % to 80 %
0 % to 80 %
0 % to 80 %
non-condensing
non-condensing
non-condensing
non-condensing
non-condensing
